Rotax 125 MAX evo Repair Manual

BRP-Rotax
REPAIR MANUAL
Chapter: Chapter 8
COOLING SYSTEM
TOPICS IN THIS CHAPTER
System description .................................................................................................................................2
Removal of radiator .................................................................................................................................4
Removal of the cooling water hose .........................................................................................................4
Inspection of cooling system ..................................................................................................................6
Radiator – inspection of components ......................................................................................................6
Installing the radiator ..............................................................................................................................7
Installation of the cooling water hoses .....................................................................................................7
Installation of the radiator on engine........................................................................................................8
Final tasks .............................................................................................................................................10
Contents This chapter describes the removal and installation of the cooling system for the ROTAX®
125 MAX evo (incl. Junior-, Mini-, Micro MAX evo) engine. The description is broken down
into subsections.
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
Chapter 8
Page 1
