Rotax 125 MAX evo Repair Manual

BRP-Rotax
REPAIR MANUAL
REMOVAL OF THE CARBURETOR AND INTAKE SILENCER
Safety
instructions
m WARNING
Danger of explosion and ignition!
Overflowing and spoilt gasoline must be absorbed immediately with a binding agent
and correctly disposed. Do not work with open flames and sources of ignition. Fuel
must not come into contact with hot parts such as engine or exhaust since this may
cause a fire!.
Preparation The following preparations should be carried out before removing the components: See
Figure: Carburetor and intake silencer.
1. Pull off fuel pipe between the fuel tank and fuel pump from the fuel pump (4) and seal it with
a screw.
2. Remove the Bowden cable. See also Chapter 3).
REMOVAL OF THE CARBURETOR AND INTAKE SILENCER
Instruction See Figure: Carburetor and intake silencer.
ATTENTION
Fuel may spill out when removing the carburetor.
ENVIRONMENTAL NOTE
Protect the environment!
Use a container to collect the fuel from the carburetor.
To remove the carburetor and intake silencer the following steps are required:
1. Remove the fuel line (1) between the fuel pump (4) and the carburetor.
2. Remove the impulse line (2).
3. Loosen the hose clamp (7).
4. Loosen 3 Allen screws (5) and remove the carburetor (3) along with the intake silencer (8),
support bracket (6) and fuel pump (4).
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
Chapter 6
Page 3
