REPAIR MANUAL
4. Secure the plastic ring with two Phillips head screws and washers. The fixing provides the
ground contact.
5. Install the rubber grommet over the positive contact.
6. Secure the bracket on the starter motor support.
7. Insert the coil springs in the cutouts of the plastic ring, press the brushes against them.
8. Carefully insert the rotor shaft.
9. Fill the starter motor support with LOCTITE 5910 in the region of the positive. This protects
the fragile carbon brushes from vibration.
10. Insert the O-ring into the starter motor support.
11. Hold the rotor shaft with a suitable tool and secure the solenoid housing on the starter motor
support.
Chapter 7
Page 16
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
