REPAIR MANUAL
15 Countersunk screw M5x12 16 Thrust washer
17
O-ring 18x3.5
18
Crank case assy. black
19
Crank case assy.
20 Gasket
21 Allen screw M6x45 22 Allen screw M6x60
23 Oil seal AS 25x38x7 24
Needle bushing 8x12x8
25 Stud M8x57/20 26 Stud M8x28/20
27
Ball bearing 6302
28
Ball bearing 6206
29
Ball bearing 6005
30
Crankshaft assy.
31
Needle cage K 15x19x20
32
Piston assy.
33
Piston pin 15x10x12.5x45.6
34
Circlip 15
35 Balance shaft 36
Impeller
37 Dowel 4x16 38
Water pump shaft
39 Oil seal A 10x26x7 40 Oil seal AS 28x38x7
41 Air vent screw M18x1.5 42
Closure cap for impulse joint
Chapter 5
Page 4
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
