We notice that:
 In the first term, the demodulated output is amplified when the discriminator delay is increased or when the
Cartesian-to-polar sampling frequency Fs is decreased,
 The sinc term filters the output with a bandwidth which is increased when the Cartesian-to-polar sampling
frequency Fs is increased or when the discriminator delay is decreased.
There are the values of the Cartesian-to-polar sampling frequency Fs corresponding to the different Pre-
Detection filters:
Pre-Detection Filter
Cartesian-to-Polar sampling frequency
10 MHz
31.25 Msps
5 MHz
31.25 Msps
3 MHz
25 Msps
1.5 MHz
25 Msps
1 MHz
25 Msps
500 kHz
5 Msps
300 kHz
2.5 Msps
150 kHz
2.5 Msps
5 to 100 kHz
312.5 ksps
Table 22: Cartesian-to-Polar Sampling Frequencies
