3.6.9.2. Number of Tones and Transmission Rank
The number of minor tones is programmable from 1 to 6 for the ESA-like standard and 1 to 8 for the USB
standard. The minor tones transmission rank is also fully programmable.
3.6.9.3. Real and Virtual Minor Tone Frequency
The virtual minor tone frequency is (in kHz): 





The real minor tone frequency is (in kHz): 



 

3.6.9.4. Ambiguity Distance
3.6.9.4.1. Integer Ratio Between Q Factors
If the ratio between two adjacent minor tone « Q » factors is an integer value, the one-way ambiguity distance is
half the wavelength of the lowest virtual minor tone.
Example 1: ESA-like mode with all real tones in the range 22-28 kHz:
TONE RANK
(1 = FIRST)
Q
P
VIRTUAL TONE
(HZ)
REAL TONE (HZ)
7
18
1
27 777.78
27 777.78
6
90
4
5 555.56
22 222.22
5
450
21
1 111.11
23 333.33
4
2 250
101
222.22
22 444.44
3
11 250
501
44.44
22 266.67
2
56 250
2 501
8.89
22 231.11
1
281 250
12 501
1.78
22 224.00
The one-way ambiguity distance is approximately:



Example 2: USB mode with a 500 kHz major tone and a very low minor tone frequency (0.625 Hz) for an
extended ambiguity distance:
TONE RANK
(1 = FIRST)
Q
P
VIRTUAL TONE
(HZ)
REAL TONE (HZ)
9
5
5
500 000
500 000
8
5
1
100 000
100 000
7
25
1
20 000
20 000
6
125
1
4 000
4 000
5
625
6
800
4 800
4
3 125
26
160
4 160
3
12 500
101
40
4 040
2
50 000
401
10
4 010
