3.3.7.4. High Bandwidth PCM: Single Viterbi Decoding
a- Nominal case (TMU table/offset 26 = 0. GUI: Frame Sync. Input = Internal):
PCM/PM,
BPSK,
QPSK,
OQPSK
demodulator
& B/S
IF inputs
Aux. inputs
BP, DM-M
decoder
Viterbi
decoder
Differential
decoder
Frame
Synchronizer
Differential
encoder
Invert/
swap
I out
(Option)
(Option)
I
Q
b- External Input to Frame Synchronizer (TMU table/offset 26 = 1. GUI: Frame Sync. Input = Ext.
F/S):
I in
Viterbi
decoder
differential
decoder
Frame
Synchronizer
(Option)
differential
encoder
invert/
swap
I out
(Option)
PCM/PM,
BPSK,
QPSK,
OQPSK
demodulator
& B/S
IF inputs
Aux. inputs
BP, DM-M
decoder
(Option)
I rail
Q rail
