COMMAND RANGING & TELEMETRY UNIT CORTEX
CRT QUANTUM USER'S MANUAL
Ref. DTU 100042
Is.Rev. 5.17
Date: Dec.
03, 2021Sept. 30, 2021
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
3.3.4.4. Doppler Computing
The Doppler measurements are computed owing to the accumulated phase interpolated every seconds
according to the formula :
,
where is the computed Doppler,
is the IF Receiver centre frequency and the accumulated phase with a
resolution of 2
-32
cycle.
The Doppler error is:
With:
Where:
And:
Where:
So:
Where D(t) is the input Doppler
A typical second-order Doppler variation of 10 Hz.s
-2
and third-order Doppler variation of 10
-4
Hz.s
-3
give a phase
error lower than (4.16x10
-3
+ 6.25x10
-9
) Hz for a sampling period Ts of 0.1 s, and lower than (41.6 + 6.25x10
-3
)
Hz for a sampling period Ts of 10s.
