Safran CORTEX CRT Quantum - Table 7: Is00427 I;O Connector

COMMAND RANGING & TELEMETRY UNIT CORTEX
CRT QUANTUM USER'S MANUAL
Ref. DTU 100042
Is.Rev. 5.17
Date: Dec.
03, 2021Sept. 30, 2021
© Safran Data Systems
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 3
Table 7: IS00427 I/O Connector Panel with BNC integration and EFC
Note : The signals connected at the EFC board are framed in red.
Connector
Usage
Connector
Usage
1
AC Power input
20
Downlink – IF Alternate 3
2
Mechanical Ground
21
1-PPS In
3
Mouse PS2 (normally unused)
22
IRIG In
4
Keyboard PS2 (normally
unused)
23
Reserved
5
IPMI – LAN
24
Reference Frequency 2
6
USB
25
AGC out 1
7
COM-1 (normally unused)
26
AGC out 2
8
VGA
27
AGC out 3
9
NIC2 – LAN
28
Video out 1
10
NIC1 – LAN
29
Video out 2
11
Reserved
30
Reserved
12
Reserved
31
Downlink – Auxiliary 1
13
Reserved
32
Downlink – Auxiliary 2
14
Reserved
33
Downlink – RF/IF Nominal 1
15
Reserved
34
Downlink – RF/IF Nominal 2
16
Uplink – IF Alternate 1
35
Downlink – RF/IF Nominal 3
17
Uplink – IF Alternate 2
36
Uplink – RF/IF Nominal 1
18
Downlink – IF Alternate 1
37
Uplink – RF/IF Nominal 2
19
Downlink – IF Alternate 2
38
Reference Frequency 1
