COMMAND RANGING & TELEMETRY UNIT CORTEX
CRT QUANTUM USER'S MANUAL
Ref. DTU 100042
Is.Rev. 5.17
Date: Dec.
03, 2021Sept. 30, 2021
© Safran Data Systems
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 5
Table 8: IS00427 I/O Connector Panel with BNC integration and External I/O connectors
Connecto
r
Usage
Connect
or
Usage
1
AC Power input
17
Uplink – IF Alternate 2
2
Mechanical Ground
18
Downlink – IF Alternate 1
3
Mouse PS2 (normally unused)
19
Downlink – IF Alternate 2
4
Keyboard PS2 (normally
unused)
20
Downlink – IF Alternate 3
5
IPMI – LAN
21
Reserved
6
USB
22
Reserved
7
COM-1 (normally unused)
23
Reference Frequency 1
8
VGA
24
Reference Frequency 2
9
NIC2 – LAN
25
AGC out 1
10
NIC1 – LAN
26
AGC out 2
11
Uplink – IF Nominal 1
27
AGC out 2
12
Uplink – IF Nominal 2
28
Video out 1
13
Downlink – IF Nominal 1
29
Video out 2
14
Downlink – IF Nominal 2
30
Reserved
15
Downlink – IF Nominal 3
31
Test Points, 1-PPS Out, Sync Pulse In
16
Uplink – IF Alternate 1
32
IRIG In, 1-PPS In, Video In, Auxiliary In
