4.2.5.2. CORTEX CRT Quantum Specific Data
The inner window shows too the following version numbers:
 SPS software layer specific to the CORTEX CRT Quantum product (example: 5,13,0,1).
 Main Signal Processing Software product file and version
 Firmware Issue: shows the Main Signal Processing board model and serial number
 MicroBlaze Version: Issue, Revision and Build number.
 Main Signal Processing board, PROMed FPGA software: MSP PCI Express FPGA: Issue and Revision.
 Optional: Main Signal Processing board, downloaded FPGA software
MSP Master FPGA: Type, Issue, Revision
MSP Slave FPGA: Issue, Revision
 Optional: Downlink Analog board, downloaded FPGA software: Issue and Revision.
 Optional: Uplink Analog board, downloaded FPGA software: Issue and Revision.
4.2.6. CORTEX CRT Quantum File System Architecture
The CORTEX CRT Quantum software can be found in the following directories. Do not move or modify these
files or directories. Theses directories are not accessible by Cortex User
ACCESS PATH
DESCRIPTION
C:\Program
Files\ZDS
Root directory
\cortex
Kernel Signal Processing Software: system
files.
\CrtxMc
s
Graphical Kernel binary
\CrtxMc
s
\Internal
Kernel Langage Translation Files
\CRT
\Msp
Microblaze Binary file (.hex)
Firmware FPGA binary files
\CRT
\Sps
CRT Signal Processing Software
\CRT
\Mcs
CRT Graphical binaries
\CRT
\Mcs\Interna
l
CRT Langage Translation Files
\Startu
p
All startup files
\Tools
\Monitor
All files for IPMIMonitor tools
