COMMAND RANGING & TELEMETRY UNIT CORTEX
CRT QUANTUM USER'S MANUAL
Ref. DTU 100042
Is.Rev. 5.17
Date: Dec.
03, 2021Sept. 30, 2021
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
3.6.3.6. Range Measurements Sampling
As the sampling rates 250 ms or 100 ms and the generation rate are asynchronous, a linear interpolation is
applied to provide the range measurements.
The Major Tone PLL is updated every (13.1072 / 8) = 1.6384 ms.
Such an interpolation generates an error. Let’s call
the interpolated phase,
the phase error, T the
1.6384 ms period and the time between 0 and T when the phase is interpolated.
where
is the received Major Tone frequency, and
the emitted one.
The Taylor expression of the phase at is:
where R2(t) the rest such that (Lagrange overestimation):
The Major Tone Doppler and second order variation are deduced from the IF input frequency f(t) and the RF
beacon frequency FRF following:
The range delay error
is:
So
A typical Doppler rate of 1000 Hz/s and a typical second order Doppler variation of 10 Hz.s
-2
give a range delay
error lower than 6.1x10
-13
s, very lower than 1 ns.
