COMMAND RANGING & TELEMETRY UNIT CORTEX
CRT QUANTUM USER'S MANUAL
Ref. DTU 100042
Is.Rev. 5.17
Date: Dec. 03, 2021Sept.
30, 2021
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
1.6.4. Doppler Measurement
Measurement technique By tracking the phase variations on the IF Receiver PLL
Measurement rate 10 ms
Measurement sampling rate User-programmable from 0.1 to 10 seconds (TCP-IP level)
Phase measurement resolution
(in degrees)
Phase values 64-bit words
Phase counter capacity ≈ 4 years (at 70 MHz)
Doppler data 32-bit frequency offsets (computed by the CORTEX software, based on
the programmed sampling rate), or 64-bit phase counter values
Performances vs noise Phase measurement jitter vs noise:
(in radian)
where 2Bn is the programmed IFR PLL loop bandwidth (in Hz)
Frequency jitter vs noise (*):
(in Hz)
where Ts is the programmed integration time (in seconds)
Range rate jitter vs noise (*):
(in Hz)
(*) Frequency & range rate computation not supported by the CORTEX.
