2.1. Cortex CRT Quantum Integration
2.1.1. Mounting of the Boards
A sticker at the rear panel of the equipment shows how the boards must be mounted in the chassis. Do not
change this setting.
All I/O ports are located at the rear panel of the chassis.
See Annex 4 for an accurate description of the PC-compatible workstation.
The cabling of the PC-compatible workstation is described in Annex 4.
2.2. Network Interfaces
2.2.1. CPU Board Ethernet Port
Connection to the Ethernet LAN is by means of two RJ45 connectors (100 Mbps or 1 Gbps Base-T standard).
The two ports can be used to either connect to separate sub-networks, or can be used in a Group on the same
network, using the Intel Pro-Teaming utility (not included).
Other connectors on the CPU board provide interfaces to other devices such as USB and VGA connectors.
The number of connectors and their mechanical characteristics depend on the model of PC-compatible
workstation. Refer to Annex 4 for a detailed description of the board.
