2.3.2.2. Integrated panel
For any signal, all characteristics and labels are identical whatever chassis is supplied, except for DL AUX signals, provided as BNC female on IS00452 and SMA female on
IS00427.
Connector
Type
Connector
Panel Label
Signal
Electrical characteristics
UPLINK
BNC Female
UL NOM IF1
IFM-1 Nominal IF output port
50-90 MHz (-3 dB bandwidth)
0 to - 80 dBm, 50 Ω
BNC Female
UL ALT IF1
IFM-1 Alternate IF output port
DC-90 MHz (-3 dB bandwidth)
- 20 dBm, 50 Ω
BNC Female
UL NOM IF2
IFM-2 Nominal IF output port
50-90 MHz (-3 dB bandwidth)
0 to - 80 dBm, 50 Ω
BNC Female
UL ALT IF2
IFM-2 Alternate IF output port
DC-90 MHz (-3 dB bandwidth)
- 20 dBm, 50 Ω
DOWNLINK
BNC Female
DL NOM IF1
Nominal IF input port # 1
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 Ω
BNC Female
DL ALT IF1
Alternate IF input port # 1
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 Ω
BNC Female
DL NOM IF2
Nominal IF input port # 2
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 Ω
BNC Female
DL ALT IF2
Alternate IF input port # 2
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 Ω
BNC Female
DL NOM IF3
Nominal IF input port # 3
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 Ω
BNC Female
DL ALT IF3
Alternate IF input port # 3
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 Ω
SMA Female (IS00427)
BNC Female (IS00452)
DL AUX-1
Auxiliary input port # 1
DC to 90 MHz
0.1 to 0.5 Vpp (at BB)
0 to -20 dBm (at IF) - 50 Ω
SMA Female (IS00427) BNC
Female
DL AUX-2
Auxiliary input port # 2
DC to 90 MHz
0.1 to 0.5 Vpp (at BB)
