SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
2-4
Section 2. Configuration
Hex Dump Selection (DSW2-4):
This setting selects the Hex Dump mode.
Print Mode Selection (DSW2-1):
This setting selects between direct thermal printing on thermally sensitive paper
and thermal transfer printing using a ribbon.
123 4 56 7 8
ON
OFF
DSW2
Sensor Type Selection (DSW2-2):
This setting selects between the use of a label gap or a reflective Eye-Mark.
DSW2-2 SETTING
Off Gap
On Eye-Mark
123 4 56 7 8
ON
OFF
DSW2
Head Check Selection (DSW2-3):
This setting checks the printer for head elements that are electrically malfunctioning.
123 4 56 7 8
ON
OFF
DSW2
DSW2-1 SETTING
Off Transfer
On Direct Therm
DSW2-3 SETTING
Off Disable
On Enable
DSW2-4 SETTING
Off Disable
On Enable
123 4 56 7 8
ON
OFF
DSW2

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
