SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
2-38
Section 2. Configuration
LCD Panel — Maintenance Mode
STEP PROCEDURE
4. Press the ENTER key to confirm your selection. The current value is
displayed on the screen, “COUNTER” or” EEPROM”.
5. Use the keys to select either YES (Clear) or NO (Do not
Clear.
6. Press the ENTER key to confirm your selection. The next screen will
appear.
xxxxxxxall clear
yes no
xxxxxxxall clear
completed
All Clear Mode
(Continued)
LCD Panel — Clear Non-Standard Protocol
The standard protocol codes used by the printer can be modified to accomodate the
requirements of different host systems. However, if the printer is to be used with a system that
does not use the custom protocol codes, they can be cleared and the default protocol codes
used. The values are:
STX = 7B
H
, ETX = 7D
H
, ESC = 5E
H
, ENQ = 40
H
, NULL = 7E
H ,
CAN = 21
H
, and OFFLINE = 5D
H
STEP PROCEDURE
1. Place DSW2-7 in the ON position. Press the LINE and FEED keys
simultaneously and power on the printer. The printer will replace the
Alternate Protocol codes with the default values and the following
screen will appear.
2. After the default setting is complete, the printer will emit three short
beeps indicating that the process is complete.
altprotocol
default complete
