SATO M-10e TT/DT Printers Service Manual
Section 2. Configuration
Download User Defined Protocol Codes
The user can define a set of custom protocol codes and download them to the printer using the
<ESC>LD command.
STEP PROCEDURE
1. Place DSW2-7 in the ON position and power on the printer. Press the
LINE key and wait for the code.
2. Transmit the download data command stream to the printer.
3. After the data has been received, the printer will beep and print a status
label. If it does not beep and print a status label, the printer did not
accept the data. Turn off the printer and check your data stream for
errors and start the download process over.
4. If the custom codes are correct, press the FEED key to accept them and
terminate the download process. If they are incorrect, turn off the printer
without pressing the FEED key and begin the process again.
To exit the mode, power off the printer, then back on.
Refer to the Operator and Technical Reference Manual for the data
stream command structure required.
user download

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
