SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
6-84
I/O modules PCD3
PCD3.W6x0
6
0 mA
20 mA
20.1 mA
I
DV
Tolerance +/- 0.5% typ.
0 20 4075 4095
19.94 mA
0.06 mA
Tolerance +/- 0.8% max.
LEDs and connection terminals
0
1
2
3
4
5
6
7
LED 0...7
Terminal 0
Description
Label
Address
Label
0
1
2
3
4
5
6
7
8
9
A0
–
A1
–
A2
–
A3
–
+
–
24VDC
PCD3.W600 4 outputs 0 - 10V
0
1
2
3
4
5
6
7
8
9
A0
–
A1
–
A2
–
A3
–
+
–
24VDC
0 - 10V -10 + 10V 0 - 20 mA
V C
U
B
Low
Mid
PCD3.W610 4 out general purpose
Terminal 9
Terminal
W
6
1
0
W
6
0
0
LED Output
0 O0
1 O1
2 O2
3 O3
Digital/analogue values
Digital values Output signals
Classic xx7 Simatic
4095 4095 27648 +20.1 mA
4075 4075 27513 +20 mA
2048 2048 13842 +10 mA
20 20 135 0 mA
0 0 0 0 mA
