I/O modules PCD3
PCD3.S100
6
Assembly instructions
1) Remove or disable power supply to the Saia PCD
®
.
2) ConnectthebusplatetotheI/Obus.Ensurethatthebusplateisrmly
 positionedintheI/Obussockets,andthatthegrooveslineupwiththeguides;
see arrows.
3) First insert the bus plate,
then locate the front plate on
the module holder.
4) Fix with the two screws provided.
