I/O modules PCD1|PCD2
PCD2.W6x0
5
20 mA
20.1 mA
19.94 mA
0 mA
0.06 mA
0 20 4075 4095
DV
I
Tolerance +/- 0.5% typ.
Tolerance +/- 0.8% max.
Terminals
9 8 7 6 5 4 3 2 1 0
A3
A2 A1 A0
Bus connector
Bus interface
Screw terminals
Uext A3 A2 A1 A0
B
U
Supply +/-15V and -5V (W610 only)
Output amplifier
V
C
Jumper ‘unipolar/bipolar’ (W610 only)
D/A converter
Jumper ‘voltage/current’ (W610 only)
Protection circuit
Stromversorgung Uext (nur W610)
mid
low
Jumper ‘reset select’ (W610 only)
Digital/analogue values
Digital values Output signals
Classic xx7 Simatic
4095 4095 27648 +20.1 mA
4075 4075 27513 +20 mA
2048 2048 13824 +10 mA
20 20 135 0 mA
0 0 0 0 mA
