Communication parameter group 07

PARAMETER DESCRIPTION 128

Normal response

Mode

Start

Address*1)

Function*2)

Start Address*3)

Number of register *4)

Check

Stop

ASCII

H3A

2char

4char

2char

0D 0A

RTU

>=10ms

8bit

2byte

>=10ms

Message

Content

*1)Address

Set the address for sending information

*2)Function code

H10

*3)Start address

Set as the start address for the register that needs to be written

*4) Number of registers

Sets the number of registers written. The maximum number is 12.

*5) Number of data

Setting range is 2~24. Set 2 times the value specified in *4).

*6) Write data

Set data division specified in *4). Write data is set in the order of high byte to low byte. Setting is

performed in the order of starting address data, starting address +1 data, starting address +2 data ...

4. Function diagnosis (H08)

In order to send the query information, the query information (function of subfunction code H00) is returned as it is,

and communication check can be performed.

Sub-function code H00 (return of query data)

The query information

Mode

Start

Address*1)

Function*2)

Subroutine *3)

Data *4)

Check

End

ASCII

H3A

2char

4char

2char

0D 0A

RTU

>=10ms

1byte

2byte

>=10ms

Normal response

Mode

Start

Address*1)

Function*2)

Sub-function *3)

Data *4)

Check

End

ASCII

H3A

2char

4char

2char

0D 0A

RTU

>=10ms

1byte

2byte

>=10ms

Query information setting

Message

Content

*1)Address

Set the address for sending information, but be unable to broadcast communication (0 is invalid)

*2)Function code

H08

*3)Sub-function code

H0000

*4)Data

The data can be set arbitrarily if the length is 2 byte. Set range is H0000~HFFFF.

5. Error response

If error is contained in the function/address/data received from the device, do function diagnosis;

However, when using function code H03 or H10 to access more than one address, if one or more data can still

operate, it will not be seen as an error.

Mode

Start

Address*1)

Function*2)

H80+function

Error code * 3)

Check

End

ASCII

H3A

2char

0D 0A

RTU

>=10ms

8bit

2byte

>=10ms
