Shihlin electric SC3 Series User Manual

Communication parameter group 07
PARAMETER DESCRIPTION 132
Item
Shihlin protocol
command code
Modbus
command code
Modbus
address
Data content and function description
Parameter
read-out
H00~H63
H03
P mode:
H0000~H018F
Parameter group
mode:
H2710~H2CFF
1.Please refer to the parameter table for data range
and decimal point position
2.Modbus address of each parameter in P
parameter mode corresponds to hexadecimal value
of parameter number. For example, Modbus
address of 04-26 (P.138) is H008A.
3. Modbus address of each parameter in parameter
group mode corresponds to hexadecimal value of
parameter number +10000. For example, Modbus
address of 04-26 (P.138) is 0x28BA.
Parameter
write-in
H80~HE3
H06/
H10
Operation
command
write
HFA
H06/
H10
H1001
H0000~HFFFF
b8~b15：reserved
b7：Emergency stop（MRS）
b6：Second function (RT)
b5：High speed (RH)
b4：Middle speed (RM)
b3：Low speed (RL)
b2：Reverse(STR)
b1：Forward (STF)
b0：reserved
Monitor
inverter real
time value
---
H03
H1014~H1020
Modbus address is as follows：
H1014：digital input terminal state
H1015：digital output terminal state
H1016：reserved
H1017：terminal 3-5 input current/voltage
H1018：reserved
H1019：DC bus voltage
H101A: inverter electronic thermal accumulation rate
H101B: inverter output wattage
H101C: inverter temperature rising accumulation
rate
H101D: inverter NTC temperature accumulation rate
H101E: motor electronic thermal accumulation rate
H101F: PID control target pressure
H1020: PID control feedback pressure
