Shihlin electric SC3 Series User Manual

Communication parameter group 07
PARAMETER DESCRIPTION 131
 Communication command list
Set the following command codes and data to perform various operation control, monitoring, etc.
Item
Shihlin protocol
command code
Modbus
command code
Modbus
address
Data content and function description
Operation mode
read out
H7B
H03
H1000
H0000: Communication mode;
H0001: External mode;
H0002: JOG Mode;
H0003: Combined mode 1;
H0004: Combined mode 2;
H0005: Combined mode 3;
H0006: Combined mode 4;
H0007: Combined mode 5;
H0008: PU Mode;
Operation mode
write in
HFB
H06/H10
Inverter status
monitoring
H7A
H03
H1001
H0000~H00FF
b15：during tuning
b14: during inverter reset
b13, b12: Reserved
b11: inverter E0 status
b10~8: Reserved
b7：alarm occurred
b6：frequency detect
b5：Parameters reset end
b4: overload
b3: frequency arrive
b2: during reverse rotation
b1: during forward rotation
b0: running
Target
frequency
write-in
EEPRO
M
HEE
H06/H10
H1009
H0000~ HFDE8：0~650.00Hz
RAM
HED
H1002
Special monitor
codes read out
H7D
H03
H1013
H0000~H0010: monitor selected information.
Please refer to special monitoring code table (H0009
reserved)
Special monitor
codes write in
HF3
H06/H10
Monitor external
operation
H7C
H03
H1012
H0000~H000F：
b0b3
b2 b1
b15~b4
RESSTF
STR
MRS0000 0000 0000
Inverter reset
HFD
H06/
H10
H1101
H9696: function of 00-02=2/P.997=1.
When communicating with upper controller, inverter
cannot return data to upper controller because
inverter is reset.
Parameter clear
HFC
H06/
H10
H1104
H5A5A
Please refer to parameter
recovery table for details.
H5566
H5959
H1103
H9966
H1106
H9696
H99AA
H9A9A
H1105
H55AA
H1102
HA5A5
