Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 180
Parameter
Number
Group
Name
Setting Range
Default
Page
P.309
05-08
IM motor stator resistance
0～99.98Ω：
According
to kw
107
P.320
11-00
Slip compensation gain
0~200%
85%
155
P.321
11-01
Torque boost filter coefficient
0～2000
20
155
P.322
11-02
Cutoff frequency point of current
filter time 1
0~30.00Hz
4.00Hz
155
P.323
11-03
Current filter time 1
0~400.00ms
According to
kw
155
P.324
11-04
Low frequency current filter time 2
0~400.00ms
According to
kw
155
P.325
11-05
High frequency current filter time 2
0~400.00ms
According to
kw
155
P.900
15-00
User registered parameter 1
P parameter mode: 0~399
Parameter group mode: 00-00~13-99
99999
158
P.901
15-01
User registered parameter 2
99999
158
P.902
15-02
User registered parameter 3
99999
158
P.903
15-03
User registered parameter 4
99999
158
P.904
15-04
User registered parameter 5
99999
158
P.905
15-05
User registered parameter 6
99999
158
P.906
15-06
User registered parameter 7
99999
158
P.907
15-07
User registered parameter 8
99999
158
P.908
15-08
User registered parameter 9
P parameter mode: 0~399
Parameter group mode: 00-00~13-99
99999
158
P.909
15-09
User registered parameter 10
99999
158
P.910
15-10
User registered parameter 11
99999
158
P.911
15-11
User registered parameter 12
99999
158
P.912
15-12
User registered parameter 13
99999
158
P.913
15-13
User registered parameter 14
99999
158
P.914
15-14
User registered parameter 15
99999
158
P.915
15-15
User registered parameter 16
99999
158
P.916
15-16
User registered parameter 17
99999
158
P.917
15-17
User registered parameter 18
99999
158
P.918
15-18
User registered parameter 19
99999
158
P.919
15-19
User registered parameter 20
99999
158
P.990
00-25
Parameter display mode setting
0: Parameter is displayed in “group mode”
0
61
1: Parameter is displayed in “sequence P
mode”
P.996
～
P.999
00-02
Parameter restoration
0: Off
0
50
1: Clear alarm history (P.996=1)
2: Reset inverter (P.997=1)
3: Restore all parameters to default
(P.998=1)
4: Restore some parameters to default 1
(P.999=1)
5: Restore some parameters to default 2
(P.999=2)
6: Restore some parameters to default 3
(P.999=3)
