Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 196
Group
Parameter
Number
Name
Setting Range
Default
Page
10-27
P.238
Amplitude acceleration time
0～360.00s/0～3600.0s
10.00s
152
10-28
P.239
Amplitude deceleration time
0～360.00s/0～3600.0s
10.00s
152
10-46
P.268
Voltage stall level
220V : 155～410V
380V
153
440V : 310～820V
760V
10-55
P.226
Reciprocating machine function
selection
0：Off
0
153
1：Turn on reciprocating machine function
10-56
P.227
Reciprocating forward limit time
0~3600.0s
0.0s
153
10-57
P.228
Reciprocating reverse limit time
0~3600.0s
0.0s
153
11-00
P.320
Slip compensation gain
0~200%
85%
155
11-01
P.321
Torque boost filter coefficient
0～2000
20
155
11-02
P.322
Cutoff frequency point of current
filter time 1
0~30.00Hz
4.00Hz
155
11-03
P.323
Current filter time 1
0~400.00ms
According to
kw
155
11-04
P.324
Low frequency current filter time 2
0~400.00ms
According to
kw
155
11-05
P.325
High frequency current filter time 2
0~400.00ms
According to
kw
155
13-00
P.89
Slip compensation coefficient
0～10
0
156
13-03
P.286
High frequency vibration
suppression factor
0.2K~5.5K model：0～1515
300
156
7.5K/11KF and above：0～1515
509
15-00
P.900
User registered parameter 1
P parameter mode: 0~399
Parameter group mode: 00-00~13-99
99999
158
15-01
P.901
User registered parameter 2
99999
158
15-02
P.902
User registered parameter 3
99999
158
15-03
P.903
User registered parameter 4
99999
158
15-04
P.904
User registered parameter 5
99999
158
15-05
P.905
User registered parameter 6
99999
158
15-06
P.906
User registered parameter 7
99999
158
15-07
P.907
User registered parameter 8
99999
158
15-08
P.908
User registered parameter 9
99999
158
15-09
P.909
User registered parameter 10
99999
158
15-10
P.910
User registered parameter 11
99999
158
15-11
P.911
User registered parameter 12
99999
158
15-12
P.912
User registered parameter 13
99999
158
15-13
P.913
User registered parameter 14
99999
158
15-14
P.914
User registered parameter 15
99999
158
15-15
P.915
User registered parameter 16
99999
158
15-16
P.916
User registered parameter 17
99999
158
15-17
P.917
User registered parameter 18
99999
158
15-18
P.918
User registered parameter 19
99999
158
15-19
P.919
User registered parameter 20
99999
158
