Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 195
Group
Parameter
Number
Name
Setting Range
Default
Page
10-09
P.57
Restart idling time
0～30.0s
99999
146
99999: Off.
10-10
P.58
Restart rising time
7.5K/11KF and below model : 0～60.0s
5.0s
146
11K/15KF and above model : 0～60.0s
10.0s
10-11
P.61
Remote control function
0: Off
0
147
X1：Remote control function, frequency save in
memory
X2：Remote control function, frequency won’t
save
X3：Remote control function, frequency won’t
save, clear frequency setting every time
STF/STR “turn off”.
X4: Remote control function, frequency save in
memory every 5s
1X:Frequency command range
01-01(P.2)~01-00 (P.1), frequency command
value from RH,RM setting
10-12
P.65
Auto reset function
0: Off.
0
149
1: When over-voltage, inverter will reset.
2: When over-current, inverter will reset.
3: When either over-voltage or over-current,
inverter will reset.
4: When any alarm occurs, inverter will reset.
10-13
P.67
Auto reset times
0: Off.
0
149
1～10: If the alarm exceeds 10-13(P.67) times,
inverter will not reset.
10-14
P.68
Auto reset waiting time
0～360.0s
6.0s
149
10-15
P.69
Auto reset times count
Read only
0
149
10-16
P.119
Forward and reverse rotation
dead time
0～3000.0s
0.0s
150
10-17
P.159
Energy-saving control function
0: Off.
0
150
1: Energy-saving mode.
10-18
P.229
Dwell function selection
0: Off.
0
151
1: Backlash compensation function.
2: Acceleration and deceleration interrupt waiting
function.
10-19
P.230
Dwell frequency at acceleration
0～650.00Hz
1.00Hz
151
10-20
P.231
Dwell time at acceleration
0～360.0s
0.5s
151
10-21
P.232
Dwell frequency at deceleration
0～650.00Hz
1.00Hz
151
10-22
P.233
Dwell time at deceleration
0～360.0s
0.5s
151
10-23
P.234
Triangular wave function
selection
0: Off.
0
152
1: If terminal function TRI is triggered, triangular
wave function will on.
2: Triangular wave function is on at all time.
10-24
P.235
Maximum amplitude
0～25.0%
10.0%
152
10-25
P.236
Amplitude compensation at
deceleration
0～50.0%
10.0%
152
10-26
P.237
Amplitude compensation at
acceleration
0～50.0%
10.0%
152
