Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 194
Group
Parameter
Number
Name
Setting Range
Default
Page
08-06
P.174
Differential time
0～1000ms
0ms
137
08-07
P.175
Abnormal deviation
0～200.0%
0.0%
137
08-08
P.176
Abnormal duration time
0～600.0s
30.0s
137
08-09
P.177
Abnormal processing mode
0: Stop freely
0
137
1: Slow down to stop
2: Alarm and continue operation
08-10
P.178
Sleep detection deviation
0～100.0%
0.0%
137
08-11
P.179
Sleep detection duration time
0～255.0s
1.0s
138
08-12
P.180
Wake-up level
0～200.0%
90.0%
138
08-13
P.181
Stop level
0～120.00Hz
40.00Hz
138
08-14
P.182
Upper integral limit
50Hz system:0～120.00Hz
50.00Hz
138
60Hz system:0～120.00Hz
60.00Hz
08-15
P.183
Deceleration step length when
stable
0～10.00Hz
0.50Hz
138
08-18
P.223
Analog feedback signal bias
0～100.0%
0.0%
138
08-19
P.224
Analog feedback signal gain
0～100.0%
100.0%
138
08-43
P.251
PID pressure range (Bar) setting
1.0~100.0
100.0
141
08-45
P.253
Analog signal feedback loss
detection time
0.0~600.0s
0.0s
141
08-46
P.254
Analog signal feedback loss
action selection
0：Alarm AErr and inverter stop freely
0
141
1：Slow down to stop then alarm AErr
2：Alarm AErr and continue operation
10-00
P.10
DC brake operating frequency
0～120.00Hz
3.00Hz
144
10-01
P.11
DC brake operating time
0～60.0s
0.5s
144
10-02
P.12
DC brake operating voltage
7.5K/11KF and below model：0～30.0%
4.0%
144
11K/15KF and above model：0～30.0%
2.0%
10-03
P.151
Zero-speed control function
selection
0: Off.
0
145
1: DC voltage braking
10-04
P.152
Voltage at zero-speed control
7.5K/11KF and below model : 0～30.0%
5.0%
145
11K/15KF and above model：0～30.0%
2.0%
10-05
P.242
DC brake before inverter start
0: Off
0
145
1: Before starting operate DC brake first.
10-06
P.243
DC brake time before inverter
start
0～60.0s
0.5s
145
10-07
P.244
DC brake voltage before inverter
start
7.5K/11KF and below model：0～30.0%
4.0%
145
11K/15KF and above model：0～30.0%
2.0%
10-08
P.150
Restart mode selection
X0：No frequency search.
0
146
X1：Reserved
X2：Decrease voltage mode
0X：Power on once.
1X：Start each time.
2X：Only instantaneous stop and restart
3X：Only valid when the inverter resets in fire
mode
