Shihlin electric SC3 Series User Manual

System parameter group 00
PARAMETER DESCRIPTION 47
Group
Parameter
Number
Name
Setting Range
Default
Page
00-07
P.161
Multi-function
display
0: Output AC voltage (V)
0
54
1: DC bus voltage. (V)
2: Inverter temperature rising accumulation rate (%)
3: Target pressure of the constant pressure system (%)
4: Feedback pressure of the constant pressure system (%)
5: Running frequency (Hz)
6: Electronic thermal accumulation rate (%)
7：Reserved
8: Signal value (mA) of 3-5 input terminals (mA/V).
9: Output power (kW).
10：Reserved
11: Forward reverse rotation signal.
Built-in keypad: Frd is forward，rEv is reverse，STOP is not
operating status.
External keypad:1 is forward , 2 is reverse, 0 is not operating
status.
12: NTC temperature (℃)
13：Motor electronic thermal accumulation rate (%)
14~18：Reserved
19: Digital terminal input state
20: Digital terminal output state
21: Actual working carrier frequency
00-08
P.37
Speed display
0：Display output frequency(not mechanical speed)
0.0
55
0.1~5000.0
1~50000
00-09
P.259
Speed display unit
selection
0: Speed display unit is 1
1
55
1: Speed display unit is 0.1
00-10
P.59
Built-in keypad set
target frequency
selection
XXX0: Use wheel on built-in keypad or external keypad to set
frequency
0
56
XXX1: Use keypad knob on external keypad to set frequency
X0XX:Frequency change done and setting saves in 30
seconds
X1XX:Frequency change done and setting saves in 10
seconds
X2XX: Every frequency change will not save
0XXX: Set frequency will work immediately when use wheel
on built-in keypad
1XXX: Set frequency will work after pressing SET when use
wheel on built-in keypad
00-11
P.72
Carrier frequency
11K/15KF and below model：1~15 kHz
5 kHz
57
15K/18.5KF and above Heavy Duty：1~15 kHz
15K/18.5KF and above Normal Duty：1~10 kHz
