Shimadzu AP W-AD Series User Manual

163
1212
SpecificationsSpecifications
1
3
5
2
4
6
7
8
12
14
13
9
10
11
Series Name X Series Y Series
Model AP124X AP224X AP324X AP124Y AP224Y AP324Y
Weighing Capacity 120g 220g 320g 120g 220g 320g
Minimum Display 0.1mg
Calibration Weight Built-in None
Range of External
Weights for
Calibration Purposes
(Recommended weight)
45 ~120.0 0 9 0g
(100g)
95~220.0090g
(200g)
95~320.0090g
(300g)
45 ~120.0 0 9 0g
(100g)
95~220.0090g
(200g)
95~320.0090g
(300g)
Repeatability
(when under weighing
capacity load)
0.1mg 0.15m g 0 .1m g 0 .15 mg
Repeatability (when
under low load) (*1)
0.1mg
(load weight 5g)
0.1mg
(load weight 10g)
0.1mg
(load weight 20g)
0.1mg
(load weight 5g)
0.1mg
(load weight 10g)
0.1mg
(load weight 20g)
Minimum weighing
value (*1)
200mg
Linearity ±0.2mg ±0.3mg ±0.2mg ±0.3mg
Display response
time for small quantity
weighing (*2*3)
Approx. 2 sec.
Response Time (*3) Approx. 2 sec.
Temperature/ Humidity
Range During Use
5~40°C, 20~85% (*4)
Sensitivity Temperature
Coefficient
±2ppm/°C (10~30°C)
Pan Size Approximately 91DIA. mm
Main Unit Dimensions Approximately 212(W) × 367(D) × 345(H)mm
Weight Approximately 7.0 kg Approximately 6.5 kg
Display Organic EL Display (Dot Matrix)
Rated Power Supply DC 12V , 1.0A
Degree of Soiling 2
Overvoltage Category II
Altitude Maximum 2,000m
Installation
Environment
Limited to Indoor Use
Input Power Supply
(AC Adapter)
AC100-240V, 0.32A 50/60Hz (*5)
I/O Terminals RS232C (D-sub9P Plug), USB device (Type B), Ionizer RS232C (D-sub9P Plug), USB device (Type B)
*1 USP41 compliant. Representative values from testing using weights equal to approximately 5% of the weighing capacity (or 5 g) at
the Shimadzu Corporation factory. The minimum display value will be affected by the environment in which the balance is installed,
so measurement needs to be carried out in the actual usage location.
*2 Time until 90% of the value of the sample quantity added in small quantity weighing (1 mg) is displayed.
*3 The response time is a representative value.
*4 No condensation.
*5 Depending on the attached AC adapter.
*6 The model names and specifications, etc., listed herein are subject to alteration without prior notice. Access the Shimadzu website
(https://www.shimadzu.com/an/balance/) for the latest information.
Ionizer (included as standard with the W-AD Series) specifications
Neutralization method Alternating current corona discharge
Ion balance (*1) ± 10 V
Neutralization range Distance (from vent): Up to approximately 400 mm
Neutralization performance (*1) Standard time to reach 100 V or less from 1 kV charged state (distance 100 mm) Reference value: 1 second
Ozone concentration 0.06 ppm or lower (at 150 mm from the center of the vent)
Discharge electrode (Material) Tungsten, Lifespan: Approximately 30,000 hours
Usage environment 0°C~40°C, 25%~85% RH or less (with no condensation)
Rated power supply DC 24 V, 1.0 A
Input power supply (AC adapter) AC 100 V, 0.58 A, 50 / 60 Hz
Contamination class (*2) 2
Overvoltage category (*2) II
Installation environment Restricted to indoor use
*1 Representative value measured 100 mm from center of vent with CPM (charge plate monitor) using 150×150 mm plate at 20 pF.
(At time of shipping from factory))
*2 Refer to the Shimadzu Corporation website (https://www.an.shimadzu.co.jp/balance/) for details.
