Siemens CP-8021 User Manual

System Components and Technical Data
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 113
DC8-037-2.02, Edition 10.2017
5.5.5.2 Operating Modes
Operating mode Interface →
optional DTE
Interface signals
Electrical Ethernet interface
(twisted pair)
X1
X4
TXD+, TXD-, RXD+, RXD-
GPRS X7
*)
(Antenna)
*)
only CP-8022
Note
Details about realization of various operation modes are given in the manual SICAM RTUs Platforms -
Configuration Automation Units and Automation Networks.
5.5.5.3 Communication
For the communication infrastructure, additional suitable transmission facilities and/or network
components may be needed.
Own Station
System System element Protocol element Remarks
SICAM A8000 CP-8000/CPC80
CP-802x/CPC80
ET84
Remote Station
System System element Protocol element Remarks
SICAM A8000 CP-8000/CPC80
CP-802x/CPC80
ET84
SICAM AK 3 CP-2016/CPCX25
CP-2019/PCCX25
ET24
SM-2558/ETA4
only 100 Mbit/s
Legacy systems
(SICAM AK, SI-
CAM TM, SI-
CAM EMIC, SI-
CAM MIC, SI-
CAM BC, Ax 1703)
CP-20xx
CP-50xx
CP-60xx
SM-2558/ETA4
SM-2557/ETA2
ETT0
SM-15x4/ET00
acc. to SICAM RTUs
IEC 60870-5-101/104 Inter-
operability
Third-party system – – acc. to SICAM RTUs
IEC 60870-5-101/104 Inter-
operability
