Service
492 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
11.2 Checks and System Display
The single system elements carry out checks of the hardware and software. If an error is de-
tected, this leads
to a signaling on the LED display
dependent of the severeness of the error possibly
to an abort of the startup
in operation to a shutdown of the modules or firmware
After an errorless startup of a system element further checks are carried out.
11.2.1 Checks during Startup
Startup (step) RY ER Error/reaction
Power-up or reset ˜ Start startup
Module defective
Massive error in the program memory
Check of the code memory (flash
PROM)
˜ PROM error (code)
Module is shut down
Startup is aborted
Check of the data memory (RAM) with
address error check
˜ RAM error (data)
Module is shut down
Startup is aborted
Check whether SD card is present ˜ SD card not present
Check of the checksum of all parame-
ter files and firmware files on the SD
card
˜ Checksum error on the SD card
Diagnosis information is set
Check whether all parameters on the
SD card are present
˜ Parameter files incomplete
Firmware is shut down
Startup is aborted
Check whether all firmware files on the
SD card are present
˜ Firmware code incomplete
Check whether the firmware code of
the subordinate system elements
(protocol elements, I/O Master Module)
is current
˜ If not, Load firmware code at a later time
Revision check of the parameters in
the parameter memory
˜ If the parameters are not current, they are
loaded from the SD card
Check parameter memory (flash-
PROM)
˜ Checksum error of the parameters
Firmware is shut down
startup is aborted
Initiate the startup of the subordinate
system elements
˜
Check for accordance of the parame-
terized HW configuration with the
mechanical configuration (I/O Modules)
˜ Configuration error
the wrongly configured or defective module
is not operational
successional modules are not operational
Check of the configuration for pulse
command output
˜ Configuration error
Pulse command output is locked for all
modules
