Siemens CP-8021 User Manual

Installation and Circuitry
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 193
DC8-037-2.02, Edition 10.2017
6.5.4.2 Mounting of the SICAM I/O Modules
The SICAM I/O Modules can be mounted as shown in following picture.
Note
The tongue and groove system integrated in the modules facilitates the correct combination. The module
is only connected correctly when the locking hook is snapped onto the DIN rail.
Caution
To increase the stability it is necessary to mount an end clamp flush left from the CP-802x housing and
flush right after the last SICAM I/O Module.
You can take information on the SICAM I/O Modules out of the following document:
Document name Item number
SICAM I/O Modules User Manual DC8-012-2
Please consider the notes in the section 2.1.5.4, Configuration Rules for I/O Modules.
X7
X6
RT X6
X3
RT X3
SI CAM A8000 CP- 8022
LK1
ETH
X1
PK1
LK4
ETH
X4
PK4
OH2
OH3
OH6
R S - 232
X2
RS-485
SIM
RS-4 85
RTX2
RY
PK7L K7
RS -2 32
ER
SICAMA8000 PS- 8620
RY ER
-
+
X1
RY
X7
X6
RTX6
X3
RTX3
SICAM A8000 CP-8022
LK1
ETH
X1
PK1
LK4
ETH
X4
PK4
OH2
OH3
OH6
R S - 232
X2
RS-48 5
SIM
RS-4 85
RTX2
RY
PK7LK7
RS-2 32
ER
SICAM A8000 PS-8620
RY ER
-
+
X1
RY RY
RY RY
