Engineering via SICAM TOOLBOX II
308 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
8.2.3.2.2 Testing Function Diagram Online
With the tool "CAEx plus", all open- and closed-loop technical tasks in processing elements of
the system can be tested online.
This function can be called via the context menu of the Master Module <firmware>, selection
ONLINE Test.
The following test functions are available:
Display and force values
Test switch input/output messages, input/output process images of the periphery
Changing the execution status of the open-/closed-loop control function
Stop controller
Start controller
Perform cold start of the resource
Perform warm start of the resource
Halt task
Continue task
Perform cold start of a task
Perform warm start of a task
Halt program
Continue program
Setting breakpoints
Real time archive
Display status information
Read and write variables
The technical description of the online test function can be found in the manual SICAM RTUs
Common Functions System and Basic System Elements, chapter "Automation", section
"Online Test".
The details for operation can be found in the CAEx plus Online Help, chapter "Target System
Connection", section "Functions for Target System Connection".
Note
With user program running, the simulated value of a variable is statically overwritten. In contrast to this,
inputs/outputs are not statically overwritten, rather only with a change to their process image (edge-
triggered).
With user program stopped, simulated values are retained.
