Page #407 background image
Engineering via SICAM WEB
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 407
DC8-037-2.02, Edition 10.2017
SICAM A8000 CP-80xx | Master module | PRE0 | Connection definition
Since the IEC 60870-5-104 parameters in SICAM PAS can only be configured once for
all connection, the following parameters must be adjusted equally in all connection def-
inition:
Parameter Value
Stat. no. <internal station number>
IP address <SICAM PAS>
Controlling/Controlled Controlled
Redundancy None
Stop behaviour Save
Failure Notify
Clear ring buffer No
Data throughput limit in receive direction 0
Data throughput limit in send direction 0
Signals in the function diagram
Existing modules deliver signals. If the CASDU is invalid, it will be replaced by the CASDU pa-
rameterized on the Master Module.
Signals via I/O Modules
If available, each signal is described by its signal name, otherwise by its IEC 60870-5-104 ad-
dress.l
The I/O modules deliver all signals assigned to software data points depending on a hardware
pin.
9.1.12.1 Synchronization of the I/O Configuration in SICAM PAS
The configuration of the I/Os can be imported in SICAM PAS, for instance via a system con-
figurator. Thereto the configuration can be downloaded as XML file via a menu item in
SICAM WEB. You will find further details in section 9.3.5, Download SICAM PAS I/O Configu-
ration.
