System Components and Technical Data
98 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
5.5 Protocol Elements
Note
The hardware of the protocol elements is integrated on the Master Module. The relevant technical data
are described there.
5.5.1 UMPMT0, UMPST0
5.5.1.1 Functions
Communication of a central station with one or several substations in multi-point traffic.
Central Station
Serial communication protocol according IEC60870-5-101
UMPT0 is central station
Unbalanced transmission Master
Network configuration
Multipoint-partyline
Multipoint-star
Max. connections: 100
System or device (application function)
Controlling station
Physical layer / data flow control
Unbalanced interchange circuit accordingV.24/V.28 standard
Transmission medium (half duplex)
Byte Frame (8E1)
Data flow control Bit in receive direction
Data flow control Bit supervision
Interoperability according to IEC 60870-5-101 Ed.1
Interoperability according to the following document:
SICAM RTUs Interoperability IEC 60870-5-101/104 (DC0-013-2)
Data acquisition by polling (station interrogation)
Continuous Interrogation of a Remote Terminal Unit
Station failure delay
Acquisition of events (transmission of data ready to be sent)
General interrogation, outstation interrogation
Clock synchronization according IEC 60870-5-101
Clock synchronization with <TI:=103> clock synchronization command
Acquisition of transmission delay (primary station) used for correction of clock syn-
chronization (with request status of link = proprietary)
Command transmission
Demand
Set control location
Check control location
