Engineering via SICAM WEB
440 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
9.2.2.2.1 Statistic Information
In the logic test page the program statistic information and the currently loaded IL are dis-
played. If no or an empty IL is loaded (no application program is running in the target device),
the logic test page shows all the values set to 0 and the IL display is empty.
Display
Information Meaning
State Running
Normal program execution
Halt
Program execution halted (the processing can be halted either manually
or by the system due to an error)
Cycle time <Set value>
Increasement of the adjusted cycle time by the system possible (see
section 9.2.1.4.1, Setting the Cycle Time)
<Actual value>
Processing time of the application program at the moment of the re-
freshment of the diagnosis menu
<Maximal value>
Maximum reached program processing time since the last startup
Memory code <Number> / 131072 bytes
Used program memory on the SD card of maximum number of bytes
(application program size)
Var <Number> / 4096 bytes
Used variables of maximum number of bytes
Test mode off / on
