Engineering via SICAM WEB
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 405
DC8-037-2.02, Edition 10.2017
The signal list can now be opened as *.csv file and modified.
• Save your changes in the signal list and save it as *.csv file
9.1.11.6.2 Import Signal List
This is how to import your signal list:
• Click on the triangle on the upper right side in order to open the workspace for defin-
ing signals
• Click on the button
You have the possibility to abort the procedure via the button .
• Click Select a file to open the selection dialog
• Select the source directory and the source file (the file type must be *.csv)
• Click on the button
The target device starts the loading procedure. The duration of the loading procedure de-
pends on the number of signals and the used communication connection.
The file is checked upon validity. If the data is valid, it is written on the SD card of the target
device. Otherwise an error indication is displayed.
After successful import, the following dialog appears:
• Click on the button
Further steps: Assigning (Master, I/O Master, I/Os), Apply.
