System Components and Technical Data
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 117
DC8-037-2.02, Edition 10.2017
Web Server
Integrated web server to display connection-/statistic-/developer information
Access to the web server with standard web browser via HTTP
Supported web browser
Microsoft Internet Explorer 9, 10, 11
Microsoft Edge
Special functions
Conversion of the time information (UTC; local time w/wo Summer-Wintertime)
Technological adaptation for measured values
Measured value change monitoring
Logging of the remote commands at the local control center
Remote parameterization/diagnostic of SICAM RTUs components via IEC 61850
______
1)
function is integrated in the Master Module
2)
with GOOSE publish and GOOSE subscribe only data attributes are supported (no data objects)!
3)
not limited (limited only by free memory)
4)
formulas for the determination of the total number of data points (n):
unbuffered reports: #LD • 54 + #CON (13 (#LD + #DP/60) • 2) + #DP • 14 = n
buffered reports: #LD • 54 + #CON (19 (#LD + #DP/60) • 2) + #DP • 14 = n
unbuffered + buffered reports: #LD • 54 + #CON (32 (#LD + #DP/60) • 2) + #DP • 14 = n
Meaning: Thereby, the following maximum value applies: n = 20000
#LD number of logical devices
#CON number of connections
#DP number of data points
5)
supported with restrictions (for details see SICAM RTUs • Ax 1703 Common Functions Protocol
Elements, chapter “LAN Communication (61850)”, section Basic Data Types” and “Conversion
IEC 60870-5-101/104 IEC 61850“)
Note
The previously mentioned functions are described in detail in the document SICAM RTUs • Ax 1703
Common Functions Protocol Elements, section "LAN Communication (61850)".
Note
At the moment the IEC 61850 Server can be parameterized with the SICAM TOOLBOX II only (not with
SICAM WEB).
5.5.6.2 Operating Modes
Operating mode Interface
optional DTE
Interface signals
Electrical Ethernet interface
(twisted pair)
X1
X4
TXD+, TXD-, RXD+, RXD-
Note
Details about realization of various operation modes are given in the manual SICAM RTUs Platforms -
Configuration Automation Units and Automation Networks.
