Engineering via SICAM TOOLBOX II
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 307
DC8-037-2.02, Edition 10.2017
8.2.3 Commissioning and Test
8.2.3.1 Loading Program Code
To load the compiled program code into the target device, the engineering PC must be con-
nected with the target device (see 7.7, Connecting Engineering PC with the Target Device).
The loading of the program code into the target device takes place jointly with the parameters
set in the “OPM II”. Thereto the tool “Parameter Loader” must be used (see also section
8.1.9.1, Loading Engineering Data).
Caution
During a loading operation, the switching off of CP-8000/CP-802x is to be absolutely avoided, since the
data on the SD card could be destroyed as a result.
You find the technical description thereto in the manual SICAM RTUs Common Functions
System and Basic System Elements, chapter “Automation”, section “Open-/Closed-Loop Con-
trol Function” | “Loading of Application Program (Reload)”.
You find the instruction for the operation in the SICAM TOOLBOX II Online Help, chapter
“Service Programs”, section “Parameter Loader”.
8.2.3.2 Test Functions
The following test functions are available:
• Simulating Function Diagram Offline
• Testing Function Diagram Online
8.2.3.2.1 Simulating Function Diagram Offline
The logic operations of a function diagram can be tested in “CAEx plus” with the Offline
simulation .
This function can be called via the context menu of the Master Module, program instance or
type instance. You can find the details thereto in the CAEx plus Online Help, chapter “Addi-
tional Products”, section “Offline Simulation”.
The oscilloscope function serves for the chronological representation of analog values and bi-
nary values during the offline simulation of the function diagram.
You find exact details thereto in the CAEx plus Online Help, chapter "Additional Products",
section "Logic Analysis with Oscilloscope Functions".
