Use Cases
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 595
DC8-037-2.02, Edition 10.2017
E.6 Usage with IPSec VPN
Features
• Communication with the control system via IEC 60870-5-104 (Ethernet interface X1 or X4
can be set by parameter)
• 1 or 2 IP addresses
• 1 subnet mask
• 1 default router
• Network settings | Security | IP security enabled = YES
Afterwards, the parameters which are required for the configuration of the IPSec connec-
tion, are available under Network settings | Security | IP security :
ICMP ping reply
IPSec VPN tunnel 1 enabled
IPSec VPN tunnel 2 enabled
Local site | Identifier (local ID)
Local site | VPN client IP address
Local site | VPN client default gateway
Local site | VPN client subnet mask
Remote site 1 | Identifier (remote ID)
Remote site 1 | IP-Address
Remote site 1 | Subnet IP address
Remote site 1 | Subnet mask
IKE security associations 1 | Internet key exchange (IKE) version
IKE security associations 1 | SA lifetime (timeout)
IKE security associations 1 | Auto-selection of authentication & en-
cryption
*)
IPSec authentication | Pre-shared Key
IPSec security associations 1 | SA lifetime (timeout)
IPSec security associations 1 | SA lifetime (data size limit)
IPSec security associations 1 | Auto-selection of authentication & en-
cryption
*)
IPSec tunnel supervision by ping 1 | Ping enabled
IPSec tunnel supervision by ping 1 | Ping cycle time
IPSec tunnel supervision by ping 1 | Ping peer IP address
___
*)
if NO:
Encryption algorithm
Authentication algorithm
Diffie Hellman group
Note
CP-8000, CP-8021, CP-8022 and the remote station must be configured in different networks when IPSec
VPN is used.
The parameters Remote site <x> |Subnet IP address and Remote site <x> |Subnet mask
are necessary for the SICAM A8000 internal router function.
The certificate SHA256 must be used (obsolete: SHA1).
In Google Chrome ® the cache must be deleted before the logon with SICAM WEB via https.
For routing in 2 tunnels it is necessary to define both remote stations (Remote site 1 and Remote site 2).
