Siemens CP-8021 User Manual

Installation and Circuitry
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 217
DC8-037-2.02, Edition 10.2017
6.11.1.2.2 CP-802x
Connection via Point-to-Point and CM-0847
Wiring for Connection CP-802x – CM-0847 Fiberoptic Interface
Connection CTS–GND: see note at page 212.
CP-8021
CP-8021
Tx Rx
CM-0847
T
x
R
x
CM-0847
CP-8022
CP-8022
RS-232
(X2)
RS-232
(X2)
Fiber optic cable
max. 1.5 km
VCC (5 V)
RXD
TXD
GND
CP-802x
X2:1
X2:2
X2:3
X2:4
X2:5
X2:6
X2:7
X2:8
1
2
3
4
5
6
7
8
CTS
RTS
VCC/5 V
TXD
RXD
GND
DCD
DTR
Shield
8-pole RJ45
male
Shield

Siemens CP-8021 Specifications

General

Product Type	Controller
Product type designation	CP-8021
Input Voltage	24 V DC
Supply voltage	24 V DC
Protection class	IP20
Power Supply	24 V DC
Mounting Type	DIN rail
Operating Temperature	0°C to 60°C
Weight	0.5 kg
