Installation and Circuitry
208 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
6.10.1.2 Pin Assignment
Interfaces at the Top
X2: RS-232 X3: RS-485 2-wire X1: Ethernet
DCD (I)
RXD (I)
TXD (O)
DTR (
O)
GND
D
SR (I)
RTS (O)
CTS (I)
n.c.
shield
n.c.
n.c.
TXD
- / RXD-
TXD+ / RXD+
O V
TXD+
TXD
-
RXD+
n.c.
n.c.
RXD
-
n.c.
n.c.
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 1 2 3 4 5 6 7 8
↕ ↕ ↕
X3 RS-422 4-wire
shield
RXD
-
RXD+
TXD
-
TXD+
0 V
1 2 3 4 5 6
DCD (I)……………. Data Carrier Detect (Input)
RXD (I)……………. Receive Data (Input)
TXD (O)…………… Transmit Data (Output)
DTR (O)……………Data Terminal Ready (selectable as voltage output 5 V or 12 V)
GND………………. Ground
DSR (I)……………. Data Send Ready (Input)
RTS (O)…………… Request To Send (Output)
CTS (I)…………….. Clear to Send (Input)
TXD+, TXD-………. Transmit Data
RXD+, RXD-……… Receive Data
Note
In case of using the RS-485 interface (X3) it is necessary to clamp the shield of the communication cable
to the DIN rail. This shield clamping should be done close to the system.
Note
The assignment of X3 is independent whether a termination is existing or not
(termination = resistance that is connected through parameter in the firmware).
SICAM CP-8000
R
S
-
4
8
5
R
S
-
4
8
5
Remote station
DIN rail
