Engineering via SICAM TOOLBOX II
306 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
8.2.2 Documentation
8.2.2.1 Cross Reference List
With the tool “CAEx plus” a cross reference list over the project hierarchy can be generated,
displayed on the screen, or printed.
The cross reference list refers alternatively to
• Entire function diagram of the selected Master Module
• Single program organization unit (POU)
It is executed via the respective context menu Cross-references .
You find the details thereto in the CAEx plus Online Help, chapter “Basics”, section “Default
Operating Elements”, section “Commands of the Pop-Up Menus”.
8.2.2.2 Open-/Closed-Loop Control Function
In the project hierarchy of the tool “CAEx plus”, by selecting one of each level, by means of
pop-up menu the function Print can be executed. The print operation is started on the de-
fault printer of the PC.
You find the details thereto in the CAEx plus Online Help, chapter “Basics”, section “Default
Operating Elements”, section “Commands of the Pop-Up Menus”, section “Print in Project
Management”.
Additional information can be found in the CAEx plus Online Help, chapter “Basics”, section
“Default Properties” as well as chapter “Lists and References”, section “Designing Printouts
with DXF”.
Further extensive possibilities for the documentation are provided by the optional function
Document Management (additional product for “CAEx plus”).
You find the details thereto in the CAEx plus Online Help, chapter “Additional Products”, sec-
tion “Documents Management (optional)”.
