Siemens CP-8021 User Manual

Installation and Circuitry
234 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
6.11.1.6.2 CP-802x
Wiring for Connection Cable for RJ45 – D-Sub (e.g. CP-8000)
Connection CTS–GND: see note at page 212.
Wiring for Connection Cable for RJ45 – RJ45 (e.g. SICAM AK 3)
Connection CTS–GND: see note at page 212.
DCD
RXD
TXD
DTR
GND
DSR
RTS
CTS
n.c.
1
2
3
4
5
6
7
8
9
X2:1
X2:2
X2:3
X2:4
X2:5
X2:6
X2:7
X2:8
1
2
3
4
5
6
7
8
CTS
RTS
VCC
TXD
RXD
GND
DCD
DTR
Shield
Shield
8-pole RJ45
male
CTS
RTS
DSR
TXD
RXD
GND
DCD
DTR
1
2
3
4
5
6
7
8
X2:1
X2:2
X2:3
X2:4
X2:5
X2:6
X2:7
X2:8
1
2
3
4
5
6
7
8
CTS
RTS
VCC
TXD
RXD
GND
DCD
DTR
Shield
Shield
8-pole RJ45
male
