Siemens CP-8021 User Manual

Installation and Circuitry
182 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
Caution
To increase the stability it is necessary to mount an end clamp flush left from the CP-8000 housing and
flush right after the last SICAM I/O Module.
You can take information on the SICAM I/O Modules out of the following document:
Document name Item number
SICAM I/O Modules User Manual DC8-012-2
Please consider the notes in the section 2.1.5.4, Configuration Rules for I/O Modules.
SICAM CMIC
F4F3F2F1
P OK
RY
ER
E TH
LK1
P K1
R S - 2 32
OH2
RTX2
R S - 4 85
OH3
RTX3
E TH
LK4
P K4
SD
X4
RY RY
RY RY
SICAM A8000 CP-8000
