Engineering via SICAM WEB
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 331
DC8-037-2.02, Edition 10.2017
Note
The selection in the drop-down boxes contains only that system elements, whose firmware has already
been loaded into the Master Module (with indication of the revision level).
By clicking you will leave the equipment program. Changes will not be saved, that
means, selected system elements will be rejected.
• In the respective drop down list, select the desired entry
• If you want to save the adjusted equipment, click
A restart request appears:
You have the possibility to abort the procedure.
• Confirm by clicking
The target device performs a restart, refer to Restart device.
During startup, the settings are stored on the SD card and the configuration pages for the se-
lected system elements are built in SICAM WEB.

Siemens CP-8021 Specifications

General

Product Type	Controller
Product type designation	CP-8021
Input Voltage	24 V DC
Supply voltage	24 V DC
Protection class	IP20
Power Supply	24 V DC
Mounting Type	DIN rail
Operating Temperature	0°C to 60°C
Weight	0.5 kg
