Engineering via SICAM WEB
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 365
DC8-037-2.02, Edition 10.2017
Category Parameter Meaning
New_IOA3 New address of the datapoint. The complete
address consists of new CASDU1, CASDU2,
IOA1, IOA2 and IOA3. New CASDU1 and
CASDU2 = 255 means no address-
conversion.
Selectivity Selective or to all remote stations
SID-BSE Source identification basic system element
SID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254; if
automatic, the SID will be learned
SID-SSE Source identification supplementary system
element
Special application input OUT_CASDU1 Address of the datapoint
OUT_CASDU2 Address of the datapoint
OUT_IOA1 Address of the datapoint
OUT_IOA2 Address of the datapoint
OUT_IOA3 Address of the datapoint
OUT_TI Type identification according to
IEC 60870-5-101/104
Inversion NO/YES
TI31_Selection OFF/ON
Fail_behav Failure behavior
Fail_subst_value Substitute value at failure
single_object_number
Command_state
• Command state not evaluate
• Command state ON before OFF
• Command state OFF before ON
Command_output_time For TI 160: 0...6200•50 ms, for TI 45, 46, 47:
• 0=no additional definition
• 1=short pulse duration
• 2=long pule duration
• 3=persistent output
SID-BSE Source identification basic system element
SID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254; if
automatic, the SID will be learned
SID-SSE Source identification supplementary system
element
Special application output Function
• OR conjunction, falling edge time delayed
• AND conjunction, falling edge time delayed
• OR conjunction, output as transients, falling
edge time delayed
• Message conversion
• OR conjunction, rising edge time delayed
Inversion NO/YES
Fail_behav_status Conjunction type
Time_delay Time delay n•100 ms
• 0 0 no delay
• 1 = 100 ms
• 255 = 25.5 s
