Engineering via SICAM WEB
388 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
Processing type Parameter Meaning
Processing grid Processing grid in seconds
0.1 to 25.5
X_0% Nominal range in the physical unit of the
input/output (0%) (S)
-50.0 to 50.0
X_100% Nominal range in the physical unit of the
input/output (100%)
-50.0 to 50.0
Y_0% Technological or normalized value 0% (S)
-1000000000000000.000 to
1000000000000000.000
Y_100% Technological or normalized value 100% (S)
-1000000000000000.000 to
1000000000000000.000
Smoothing 0 - 99 in %. 0% = no smoothing, 99% = high-
est possible smoothing
0 to 99
MV_conv_free_Xl Limit of not plausible range. Parameter is only
effective, if the parameter ze-
ro_range_a_MV_conv is set to free
parametrizable (in the physical unit of the
input) (S)
-103.00 to 103.00
zero_range_Xzu Upper limit of zero range in % of X_100% (S)
-103.00 to 103.00
zero_range_Xzl Lower limit of zero range in % of X_100% (S)
-103.00 to 103.00
zero_range_Yz Technological or normalized value of zero
range (S)
-1000000000000000.000 to
1000000000000000.000
zero_range_a MV_conv Zero range suppression (and check of the
plausibility limits) either standard or free
parametrizable (S)
• Standard
• Free configurable
OV_suppr_t OV suppression time in seconds, 0=no OV
suppression
0 to 255
standard load The measuring range can be adapted with
changing the load (S)
NO/YES
AI_U – voltage value
acqisition
line frequency The noise rejection takes place for the
parametrized line frequency
• 50 Hz
• 60 Hz
• 16.7 Hz
Zero range Zero range suppression (and check of the
plausibility limits) (S)
NO/YES
thresh_additive Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 1000.0
