Engineering via SICAM WEB
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 391
DC8-037-2.02, Edition 10.2017
Processing type Parameter Meaning
SW_REV - revision –
SW_T_VT_NOK – volta-
ge transformer nok
SID-BSE Source identification basic system element
SID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254; if
automatic, the SID will be learned
SID-SSE Source identification supplementary system
element
SW_UI - software volt-
age, current
thresh_additive Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 1000.0
thresh_uncond Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 103.00
T_AI_I – current trans-
former input
line_frequency_transformer configuration of line frequency
• 50 Hz
• 60 Hz
thresh_additive Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 1000.0
thresh_uncond Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 103.00
transformer_X_100% Nominal range of transformer/input: second-
ary
• 8510: 1 A - 8511: Low Power (225 mV)
• 8510: 5 A - 8511: Low Power (225 mV)
transformer_Y_100% Nominal range of transformer: primary in kV
or 230 V or in Ampere
50 to 800
transformer_Y_100%_5A Nominal range of 5A - current transformer: in
Ampere. Only valid for AI-
8510 and X_100% =
5 A.
50 to 400
Overrange Definition of the overrange for QDS 'OV' in %
of the nominal range of the transformer
T_AI_U - voltage trans-
former input
line_frequency_transformer configuration of line frequency
• 50 Hz
• 60 Hz
primary_voltage_correction Correction value for primary voltage
thresh_additive Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 1000.0
thresh_uncond Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 103.00
transformer_X_100% Nominal range of transformer/input: second-
ary
• 8510: 100 V/SQRT3 - 8511: 3.25 V/SQRT3
• 8510: 230 V - 8511: 3.25 V/SQRT3
• 8510: 400 V/SQRT3 - 8511: 3.25 V/SQRT3
transformer_Y_100% Nominal range of transformer: primary in kV
or 230 V or in Ampere
1.0 to 36.0
